Frigidaire 5304513274 Dishwasher Door Hinge Kit OEM Part

My husband took the door apart replaced hinges in less than 15 minutes. Very easy to do yourself rather then paying a lot of money for someone to come out to do it for you. I would have to say that the customer service was very helpful told me exactly what I needed.

My husband took the door apart replaced hinges in less than 15 minutes. Very easy to do yourself rather then paying a lot of money for someone to come out to do it for you. I would have to say that the customer service was very helpful told me exactly what I needed.

My daughter fell on the open dishwasher door and bent the hinges so that the door was opening too far and the bottom rack could roll down slope right onto the floor. I initially removed the door cover and pulled the dishwasher out to investigate and could clearly see the bend in the hinges. Ordered the replacement hinges from AppliancePartsPros.com. Replacement: Need Philips, and Torx screwdrivers, adjustable wrench and/or nut driver. 1. Remove kickplate. 2. Remove 2 screws attaching the dishwasher to the counter. 3. Open the door and remove screws holding the door cover on (2 philips screws, two torx screws).You should be able to leave the screws across the top of the door. 4. Hinge should now be visible. Close the door and remove the spring cable that is attached to the hinge. 5. Remove two bolts on the hinge arm (need wrench and torx). 6. Remove pivot bolt (torx). 7. Hinge is removed. 8. Make sure you use the correct replacement hinge (ie left side hinge). 9. Repeat 4 - 8 for the opposite side. 10. Reverse all steps. Done!

AppliancePartPro.com's 24 hour help service explained to me at 9 PM that the problem was not the springs being weak, but that the arm assays had probably been bent by someone falling on the door in the past. Order the parts. They arrived quickly. Easy repair, but no indication anywhere that a six-pointed star driver was needed to loosen all the screws holding the door to the assys. After some frustration was able to secure the correct tool and make the repair.

With appliance pro help with parts and their awesome videos. replaced the door seal, the bottom seal put in the splash gaurds. all which were a very easy fix. I replaced the hinges on both sides of the door because we had someone fall on the door. the parts came within two days after ordering them. I recommend yiour web site to any one I hear that needs appliance repair. Can't say enough on how your company has helped me make my job as the maintenance director for a medium size YMCA easier. love your product and tech. support. a BIG THANK you and your staff.
