Parts for Thermador RDDS30V: 04 - Sequence Manifold Assembly Parts

Saddle clamp secures gas lines and wiring on cooktops and ranges. Replace if cracked, loose, or missing to prevent rattling and ensure safe operation.

Used to hold down the jet holder assembly.

This tubing assembly routes water inside the appliance to maintain proper flow and sealing where factory tubing is required. It replaces damaged or leaking tubing to restore normal water routing and prevent leaks. What it does:

• Replaces worn, cracked, or pinched tubing that can cause leaks or reduced water flow
• Restores proper internal water routing to dispensers/valves or drain lines
• Helps stop visible water on the floor or pooling near appliance bases
• Maintains secure connections where the original tubing was installed

• Turn off power to the appliance and shut off the water supply before servicing
• Inspect connection fittings and clamps; replace any damaged clips or seals
• Avoid sharp bends or kinks when routing the tubing; secure with existing brackets

Replace the tubing assembly in your range when the tube is cracked, kinked, leaking, or damaged. Connects internal components for proper operation.

This tubing assembly routes water inside the refrigerator to the dispenser/ice system, restoring a sealed water path and reliable flow. Use it to replace cracked, kinked, or leaking tubing for better water delivery. What it does:

• Carries water from the inlet to the dispenser/ice components to enable ice and water dispensing
• Stops leaks and seepage caused by cracked or damaged tubing
• Restores proper water routing when bends or kinks restrict flow

• Tubing assembly

• Turn off the refrigerator and shut off the water supply before starting work
• Drain any remaining water from lines and have a towel/container ready for spills
• Inspect connections and use new fittings or seals if the old ones are damaged

Burner won't light or has no gas flow? This top burner valve controls gas to individual burners. Moderate DIY repair with basic tools needed.

Jet holder assembly routes gas through the orifice to the burner. Replace if cracked, corroded, or stripped threads prevent secure installation.

The Jet Holder with Nut is an OEM part for Bosch ranges and cooktops. It holds precisely machined jets that control gas flow from each burner valve.

Causes may be wear and deterioration from prolonged heating exposure. Physical impacts or damage accumulation over time could also compromise the jet holder.

Symptoms of a bad jet holder can include:

• Inability to adjust or maintain proper flame stability and heat output
• Irregular or uneven flame patterns between surface burners
• Potential gas leaks observed at jet connections

This genuine OEM Bosch part is also compatible with Thermador, Gaggenau and select Kenmore models.

This is a redesigned kit. It is strongly recommended to have a certified Thermador technician install this kit as some modifications may be necessary.

Burner won't spark or ignite? This spark switch signals the ignition module to light gas burners. Common DIY repair with basic tools, 15-30 minutes.
