Parts for Electrolux E30DF74GPS3: 05 - Burner Parts

This replacement drain tube routes condensation and defrost water away from the evaporator area to the refrigerator drain system, helping prevent pooling and ice buildup. It restores proper water flow when the original tube is cracked or clogged. What it does:

• Channels defrost and condensation water from the evaporator to the drain pan or drain trough
• Helps prevent water pooling inside the fresh food or freezer compartments
• Reduces risk of ice buildup and associated odors caused by standing water
• Restores proper drainage after physical damage, cracks, or blockages

• Disconnect power to the appliance and, if applicable, shut off the water supply before starting.
• Remove access panels as needed to reach the evaporator/drain area; keep track of fasteners.
• Inspect surrounding grommets and fittings; replace any damaged seals to prevent leaks.

Fix a burner that won't light, won't stay lit, or has uneven flames with this top burner valve. Controls gas flow to individual burners on gas cooktops.

Wire harness for ranges. Connects electrical components inside the appliance. Replace if wires are frayed, damaged, or connections are loose or broken.

Secures the ignitor assembly to your gas cooktop burner base. Replace if screw head is stripped, threads damaged, or screw is missing after disassembly.

Replacement surface burner head for gas ranges and cooktops. Distributes gas through precision ports for even flame. Needed when original is clogged, damaged, or corroded.

Replacement burner head for gas ranges and cooktops. Mounts over the orifice to distribute flame evenly. Needed when original is cracked or damaged.

This ignitor orifice assembly delivers and meters gas to the oven/range ignitor so burners light reliably. Replace a damaged or clogged assembly to restore consistent ignition and proper burner lighting on compatible gas appliances. What it does:

• Routes and meters gas flow to the ignitor so the burner can light
• Supports consistent ignition timing for oven and range burners
• Commonly used when an oven won't light, has weak or uneven flames, or ignition failures occur
• Helps prevent gas leaks by providing a secure connection when installed correctly

• Disconnect power and shut off the gas supply before starting any work
• Only install on compatible appliances; follow the OEM instructions
• Hand-tighten connections and check for leaks with a soapy-water solution after restoring gas

Combines spark igniter electrode with orifice holder for gas surface burners. Replace when cracked, broken, or no longer securely holding components in place.

Replacement mounting bracket for range installation. Secures appliance components in place. Order if your original bracket is bent, broken, or missing.

Burner orifice regulates gas flow to your range burners. Replace if clogged with debris, corroded, or damaged to restore proper combustion and heat output.

Burner orifice controls gas and air flow to cooktop burners. Replace if cracked, corroded, or when converting between natural gas and propane fuel types.

Secures gas valve assemblies and mounting brackets to your range. Replace if screw is stripped, missing, or corroded to keep valve hardware stable.

Converts your range from natural gas to liquid propane. Includes orifices for burners and oven. Replace when switching fuel types or if original orifices are damaged or missing.

This is a replacement screw used to secure appliance panels and components. It restores proper fastening so panels, trim, or assemblies stay tight and reduce vibration or rattling. What it does

• Fastens panels, brackets, or trim to the appliance chassis
• Helps stop loose or vibrating panels and trim pieces
• Restores proper alignment where a missing or stripped screw causes gaps or movement
• Use when the original screw is missing, damaged, or corroded

• One replacement screw as shown

• Disconnect power to the appliance before starting any repair
• Use the correct screwdriver or bit to avoid stripping the screw head
• Tighten until snug; avoid over-torquing which can strip threads or crack plastic
• Keep removed screws in a safe place; this screw matches the original before installation

This replacement screw secures appliance panels, brackets, and internal components. It restores a tight, rattle-free fit and proper alignment when an original fastener is missing, stripped, or corroded.

• Fastens metal or plastic parts to the cabinet/frame
• Helps maintain alignment and reduce vibration or rattling
• Direct replacement for lost, damaged, or rusted hardware
• Keeps covers and brackets safely in place

• Disconnect power before servicing; for gas appliances, also shut off gas supply
• Match one-for-one with the original screw; verify length/type before installation
• Start threads by hand to avoid cross-threading; tighten snugly without overtightening
• Use the correct driver bit to prevent stripping the screw head
