Parts for Kenmore 790.36939905 (79036939905, 790 36939905): Burner Parts

This replacement tube routes defrost and condensation water from the freezer/refrigerator to the drain system, helping prevent leaks and ice buildup in the cabinet. It's a simple, direct replacement that restores proper water flow. What it does:

• Channels defrost and condensate water into the refrigerator drain system to prevent pooling
• Helps stop visible leaks and water pooling inside the fresh food or freezer sections
• Reduces risk of ice buildup from trapped melt water in the cabinet
• Works with the factory drain path and drain pan to maintain normal condensation removal

• One replacement tube

• Inspect and clean the drain passage before installing to ensure proper flow
• Secure tube to existing fittings/clips; do not force or over-bend the tube
• Turn off power to the appliance before accessing internal components

If your burner won't light or the flame is too high or too low, this gas valve controls flow to restore proper ignition and flame adjustment on your cooktop.

Secures the ignitor assembly to your gas cooktop burner base. Replace if screw head is stripped, threads damaged, or screw is missing after disassembly.

Replaces cracked or corroded sealed burner head on gas ranges and cooktops. Restores proper flame distribution when original part is damaged or clogged.

Replacement surface burner head for gas ranges and cooktops. Distributes gas through precision ports for even flame. Needed when original is clogged, damaged, or corroded.

Replacement burner head for gas ranges and cooktops. Mounts over the orifice to distribute flame evenly. Needed when original is cracked or damaged.

Replacement gas burner for ranges and cooktops. Restores even flame distribution when original is clogged, damaged, or worn from boilovers and daily use.

This ignitor orifice assembly delivers and meters gas to the oven/range ignitor so burners light reliably. Replace a damaged or clogged assembly to restore consistent ignition and proper burner lighting on compatible gas appliances. What it does:

• Routes and meters gas flow to the ignitor so the burner can light
• Supports consistent ignition timing for oven and range burners
• Commonly used when an oven won't light, has weak or uneven flames, or ignition failures occur
• Helps prevent gas leaks by providing a secure connection when installed correctly

• Disconnect power and shut off the gas supply before starting any work
• Only install on compatible appliances; follow the OEM instructions
• Hand-tighten connections and check for leaks with a soapy-water solution after restoring gas

This ignitor orifice assembly replaces the oven's igniter/orifice mounting that controls gas flow to the burner, restoring proper ignition and reliable burner operation when the original assembly is damaged or clogged. What it does:

• Holds the igniter and orifice in the correct position for safe oven burner ignition
• Regulates gas flow to the burner tip for stable flame and consistent heating
• Commonly used when the oven won't light, ignition is slow, or flame is weak/uneven
• Helps prevent intermittent ignition caused by a damaged, bent, or clogged assembly

• Shut off the gas supply and disconnect power before starting any work
• Accessible from the oven interior or rear panel depending on model; may require removing burner components
• Tighten fittings to manufacturer torque; replace damaged gaskets or seals

Combines spark igniter electrode with orifice holder for gas surface burners. Replace when cracked, broken, or no longer securely holding components in place.

Ignitor and orifice assembly for gas range burners. Replace if cracked, damaged, or worn to restore proper ignition. Installs at burner base.

A direct-replacement tube that routes fluid inside the appliance to restore proper flow and help stop leaks from a damaged or cracked line. Use this tube when the original is broken, split, or degraded. What it does:

• Replaces a damaged internal tube to re-establish fluid flow and routing
• Helps stop leaks caused by cracks, holes or brittle tubing
• Prevents intermittent flow problems tied to collapsed or kinked lines
• Restores proper operation of the system components the tube connects

• One replacement tube

• Inspect the tubing path and fittings before installing; replace any damaged clamps or connectors
• Disconnect power and water supply (if applicable) before starting work
• Cut tubing squarely and seat fully into fittings; use new clamps where required

Regulates gas pressure from your home's supply line to the range burners. Replace if cracked, leaking gas, causing whining noises, or damaged threads.

Burner won't light or flame is weak? This gas valve controls flow to your range surface burner for reliable ignition and heat control. Moderate DIY.

Replace a cracked, worn, or damaged electric range surface burner element. Installs in the cooktop receptacle to restore a functional heating zone.

Oven won't light or ignites with a loud pop? A faulty igniter is usually the cause. Simple DIY fix—disconnect two screws and wire nuts to replace.

Natural gas burner orifice meters gas flow to range burners. Replace worn or clogged orifices for stable flame. Used for LP to natural gas conversions.

Burner orifice regulates gas flow to your range burners. Replace if clogged with debris, corroded, or damaged to restore proper combustion and heat output.

Burner orifice controls gas and air flow to cooktop burners. Replace if cracked, corroded, or when converting between natural gas and propane fuel types.

Burner orifice for gas ranges and cooktops. Controls gas flow to burner. Replace if cracked, corroded, or when converting between natural gas and propane.

Secures gas valve assemblies and mounting brackets to your range. Replace if screw is stripped, missing, or corroded to keep valve hardware stable.

Replace a damaged or frayed range wire harness. This internal wiring component connects electrical systems inside your range. Order when wires are cut or worn.

This wiring harness routes power and signals between a refrigerator's control board and major components, restoring reliable electrical connections for proper operation. Use it when connectors are damaged or wiring is worn. What it does:

• Carries power and control signals between the main control and components
• Replaces burned, frayed, or broken wire runs that cause intermittent or no component operation
• Restores secure connector interfaces to fix flickering lights, non-running fans, or no cooling symptoms
• Preserves correct wiring routing to prevent shorts and maintain safe operation

• One wiring harness assembly as shown

• Always disconnect power to the appliance before starting work
• Handle connectors gently; match keyed plugs and secure all mating clips
• Route harness along original paths and secure with existing clips or ties to avoid pinching
• Replace any damaged connectors or terminals to ensure a reliable connection

Replacement #8 x 0.500 inch screw for securing panels, trim, and brackets in appliances. Needed when original fasteners are stripped, lost, or missing.

This is a replacement screw used to secure appliance panels and components. It restores proper fastening so panels, trim, or assemblies stay tight and reduce vibration or rattling. What it does

• Fastens panels, brackets, or trim to the appliance chassis
• Helps stop loose or vibrating panels and trim pieces
• Restores proper alignment where a missing or stripped screw causes gaps or movement
• Use when the original screw is missing, damaged, or corroded

• One replacement screw as shown

• Disconnect power to the appliance before starting any repair
• Use the correct screwdriver or bit to avoid stripping the screw head
• Tighten until snug; avoid over-torquing which can strip threads or crack plastic
• Keep removed screws in a safe place; this screw matches the original before installation

Converting your range to a different gas type? This conversion kit includes orifices and fittings to safely switch fuel types. Moderate DIY install.
