Parts for Bosch HDS7282U/01: Drawer Parts

This is a replacement oven control board manufactured by Bosch. The oven control board is the oven's brain and handles all the functions. It also includes the display and provides users with the ability to control functionality, like bake and broil, setting timers, and more. While the oven control board does not include moving parts, heat and moisture can damage soldered components and lead to failure. Signs that the control board may need to be replaced include lack of information on the display, inability to control specific functions, or complete lack of operability. Note that this part is often misdiagnosed, so make sure to check the old board's operability with a multimeter before replacing it. To replace the oven control board, first remove the exterior cowling. Locate the wiring harness and disconnect it before removing the mounting screws. Install the replacement part following these steps in reverse.This genuine OEM part is sold individually. It only fits Bosch Thermador ovens.

Replace your worn, cracked, or missing range oven control knob. Restores smooth temperature selection and cooking function control with a precise fit.

Replace your gas range's scratched, dented, or discolored stainless steel main top. This cooktop surface panel restores appearance and covers damage.

This replacement grill grid restores a flat, stable cooking surface so food cooks evenly and stays off the burner. Designed to fit compatible Bosch countertop grills and grilling modules for reliable performance. What it does:

• Provides a stable, heat-resistant surface for grilling and searing foods
• Keeps food elevated above the burner for even heat distribution
• Replaces bent, warped, or damaged grill surfaces that cause uneven cooking
• Helps prevent food from falling into the burner area during use

• One grill grid

• For safety, disconnect power and allow appliance to cool completely before removing or installing the grid
• Handle with care—edges may be sharp and surfaces hot after recent use
• Slide or position the grid into the existing support rails; no special tools typically required

Gas range burner cap sits atop the burner to distribute flames evenly for cooking. Replace if cracked, warped, or causing uneven flames. Verify fit with your model number before ordering.

Fix wobbly burners or uneven flames with this gas range burner housing. Secures surface burner assembly for stable operation and proper alignment.

Burner cap for gas ranges. Sits atop the burner assembly to control and diffuse the flame. Replace if cracked, chipped, worn, or missing.

Fix a loose or misaligned cooktop burner with this burner housing. Secures the burner head and igniter for stable flames and even heating on your range.

Replacement burner cap for gas ranges. Covers the burner head assembly. Replace if cracked, chipped, discolored, or missing to restore appearance.

Fix uneven flames or loose burner heads with a new gas range burner housing. This metal assembly secures your burner and ignition for stable cooking.

Burner cap for gas cooktops and ranges. Sits on top of the burner head to distribute flame. Replace if cracked, chipped, discolored, or missing.

If your range has intermittent power issues or components that won't operate, a damaged cable harness may be the cause. This wiring assembly restores connections.

Decor frame for gas ranges. Installs around the control panel to provide a finished appearance. Order a replacement if your frame is cracked or damaged.

Control panel for gas ranges. Installs on the front of the unit. Replace if the panel is cracked, broken, or showing signs of wear and damage.

This mounting bracket secures appliance components in place to restore proper alignment and stability. It's a simple replacement part that helps reduce rattling and supports correct panel or assembly positioning. What it does:

• Secures a panel or assembly to the appliance frame to prevent movement and vibration
• Restores proper alignment for doors, panels, or internal components
• Helps stop rattling, noises, or loose components that occur when a support bracket fails
• Provides a direct mechanical replacement—no electrical function

• One replacement mounting bracket

• High-level: remove power and water to the appliance before starting repairs
• Use basic hand tools; keep fasteners from the original part for reinstallation unless new ones are supplied
• If the bracket mounts a door or heavy panel, support the panel during removal and reinstallation to avoid damage

Fix range control issues or power problems with this cable harness. Common fix for unresponsive controls or electrical faults. Moderate DIY repair.

The Oven Light Switch is an OEM part for Bosch ranges. It engages convenient interior illumination through a single motion, allowing monitoring of baked goods without compromising temps.

Causes of a bad oven light switch can include failures from the natural stresses of constant clicking associated with opening and closing the oven door.

Symptoms of a bad oven light switch include:

• Dim or unresponsive lights even when the door is opened properly
• Inability to turn lights off, leaving them burning needlessly
• Stuck in either the on or off position without toggle functionality
• Potentially hazardous exposed live terminals under switch housings

This OEM Bosch part can also be used on Thermador and Gaggenau appliances.

Mounting holder that secures burner assemblies to the cooktop. Replace if cracked, rusted, or missing to restore proper burner positioning and stability.

Mounting clip that secures burners to your gas range cooktop. Replace if rusted, broken, or missing to properly position burners and prevent rattling.

Fix weak or uneven burner flames with a new orifice holder assembly. Secures gas flow orifices for proper flame control. DIY-friendly, under 30 minutes.

Uneven flame or poor ignition? This burner orifice meters gas flow to create a stable flame. Replace clogged or damaged orifices to restore performance.

This water inlet valve controls dishwasher water flow during fill cycles, restoring proper filling and preventing overfill. Replace a faulty valve to stop no-fill, slow-fill, or continuous-fill issues and restore normal wash cycles. What it does:

• Opens and closes to admit water into the dishwasher during fill cycles
• Maintains correct water flow and pressure for proper wash performance
• Stops water flow if inlet fails closed or prevents filling if stuck open
• Common symptom link: dishwasher won't fill, fills slowly, or shows error/overflow conditions

• One water inlet valve

• Disconnect power and shut off the water supply before starting
• Turn off the breaker; water and electrical safety first
• Basic hand tools typically required; keep track of hose clamps and fittings
• Inspect inlet hoses and gaskets and tighten or replace clamps as needed

This water inlet valve controls the flow of water into the appliance so cycles fill when needed and stop to prevent overfilling. Replaces a worn or failed inlet valve to restore reliable water fill operation. What it does:

• Opens and closes to allow water into the appliance during fill cycles
• Works with the control board and float/sensors to prevent overfill
• Common repair for no-fill, slow-fill, or continuous-fill symptoms
• Helps stop leaks caused by valves that fail to fully close

• Turn off power and shut off the water supply before starting
• Drain residual water and relieve pressure from the line before disconnecting
• Inspect and replace any worn inlet hoses, clamps, or seals during installation
• Test cycles and check for leaks after installation

Fixes burner flame issues on gas ranges. Controls gas flow for consistent cooking temperatures. Replacing a worn valve restores precise flame control.

Secures flexible hoses to fittings on your range to prevent leaks. Replace if connections are loose or clamp is damaged. Verify fit with your model.

Fixes inconsistent oven temperatures and burner performance. This pressure regulator restores steady fuel flow control for reliable range operation.

This dishwasher water sensor monitors wash-water conditions so the control can adjust cycle time, rinses, and heating for consistent performance. Replace a failed sensor to restore reliable cleaning results and proper automatic cycle adjustments. What it does

• Detects water conditions during the wash cycle and reports to the control
• Helps the dishwasher optimize cycle length, rinses, and energy use
• Common symptoms: unusually long or short cycles, inconsistent cleaning, or sensor-related error messages
• Trigger erratic cycle behavior when the sensor is faulty or contaminated

• One sensor assembly

• Disconnect power and turn off water before servicing
• Access is typically from the underside; place a towel or pan to catch residual water
• Transfer/seat the seal properly if present; fully engage the locking tabs and reconnect the harness
• After installation, run a quick cycle and check for leaks and proper operation

Fix intermittent power or component failure with this range socket electrical connector. Restores secure wiring connections in electric and gas ranges.

Replace your worn oven door gasket to restore a tight seal, prevent heat loss, and maintain consistent baking temperatures. Confirm fit with your model number.

Restore oven visibility with this complete light assembly. Replace when bulb won't light, lens is cracked, or socket is damaged. Verify fit with your model.

This heating element is the direct-replacement heater assembly that provides the heat source for compatible appliances, restoring proper heating so cycles reach the temperatures needed for effective drying or cleaning. What it does:

• Generates heat for the appliance's thermal system (air or water heating depending on model).
• Replaces a failed or damaged heater element to restore normal temperature rise.
• Common symptoms it may fix: no heat, weak/no drying or cleaning performance, or unusually long cycles.
• Works as part of the appliance's safety and temperature-control circuit (thermostats or sensors may also be involved).

• Always disconnect power (and water, if applicable) before replacing the element.
• Allow the appliance to cool fully and wear protective gloves; heating elements can have sharp edges.
• After installation, restore power and run a short test cycle to check for any error codes.

The Sensor is an OEM part for Bosch ovens and ranges. It detects and monitors the actual interior temperature to maintain precise baking and roasting conditions.

Causes of a bad temperature sensor can include wear from prolonged heat exposure within the oven cavity. Physical damage, moisture intrusion or circuitry malfunctions may also lead to sensor failure over time.

Symptoms of a bad oven temperature sensor include:

• Inability to accurately read or achieve set target temperatures
• Fluctuations in readings displayed
• Cooking modes like bake and broil functioning abnormally

This genuine OEM Bosch part is also compatible with Thermador, Gaggenau and select Kenmore models.

Catalyzer component for electric ovens and ranges. Installs inside the oven cavity. Order a replacement if your catalyzer is cracked, damaged, or missing.

The Convection Fan Motor is an OEM component specifically designed for Bosch combination and convection steam oven ranges. Located within the oven cavity, it powers the convection fan and circulation of hot air.

Symptoms of a bad convection motor include:

• Failure to achieve even heat distribution within the oven
• Loud grinding noises or vibrations from the fan
• Inability to select convection cooking modes
• Burning smells indicating possible overheating

Causes of failure may involve normal wear over extended use. Blocked ventilation from food debris could overload the motor. Accidental liquid spillage presents corrosion risks.

Replacing with this genuine Bosch motor restores essential airflow. Compatible with 500 series models, it features a permanently lubricated design for durable performance. Backed by Bosch quality, this convection replacement ensures reliable cooking for years to come. It is also compatible with Thermador and Gaggenau ranges.


Restore even baking when your oven heats unevenly. This convection fan blade circulates hot air for consistent cooking. Moderate DIY install.

This Terminal Box is an OEM part for Bosch Built-In Ovens. Integral to the oven's electrical system, this component serves as a secure connection point for various electrical wires within the appliance.

A common issue with a malfunctioning Terminal Box is loose connections or damage to the terminal block due to heat exposure or aging.

Symptoms of a defective Terminal Box may include:

• Inconsistent power supply to the oven
• Non-functional heating elements
• Sparks or electrical arcing within the terminal box area

This OEM Bosch part is also compatible with Thermador, Gaggenau, and some Kenmore models.

Secures your range door and allows smooth pivoting for proper alignment and seal. Replace if your door won't close fully, sags, or doesn't seat correctly.

Replace your worn or broken range door hinge to restore proper door alignment and smooth operation. This hinge pivots and supports the oven door.

Leveling foot for electric and gas ranges. Adjustable metal foot installs at base corner. Replace if cracked, broken, or missing to level your range.

Restores smooth rack gliding in your oven. Replace when racks stick, scrape, or don't extend fully. Confirm fit with your model number before ordering.

This rail guides and supports oven racks as they slide in and out of your range. Replace if bent, cracked, or missing to restore smooth rack operation.

Replacement storage drawer for gas ranges. Restores under-appliance space and smooth sliding. Replaces cracked, broken, or worn drawers.

Fix an oven door stuck closed after a cleaning cycle or error code 41. This door latch assembly restores normal lock/unlock operation on gas ranges.

Secures internal components and panels to restore proper alignment in your range. Replace when bracket is broken, cracked, or missing to fix loose parts.

This wire shelf provides a stable, ventilated storage surface inside the refrigerator to organize food and improve airflow for even cooling. It replaces a damaged, bent or missing shelf to restore usable interior storage space. What it does:

• Replaces a bent, rusted or broken refrigerator wire shelf that no longer supports items safely
• Restores flat, secure storage for food containers, bottles and produce
• Helps maintain proper air circulation in the compartment for more consistent cooling
• Fits into existing shelf tracks or supports designed for factory wire shelves

• One replacement wire shelf

• Slide shelf into existing tracks/supports; no tools typically required for drop-in style shelves
• Handle carefully to avoid sharp wire ends; wear gloves if needed
• Only replace with the correct part number for secure fit and safe operation

This grille for pan is a replacement trim piece that restores proper airflow and appearance around the appliance pan. It helps keep the pan area protected and looking finished after repair. What it does:

• Covers and ventilates the pan opening to help direct airflow and prevent debris entry
• Replaces a cracked, warped, or missing grille to restore fit and finish
• Helps eliminate rattling or rubbing caused by a damaged trim piece
• Matches OEM fit so it installs cleanly with the original mounting points

• Install requires removal of the surrounding trim or access panel; follow your appliance manual
• Handle carefully to avoid scratching the finish; use non-marring tools as needed
• Disconnect power to the appliance before working in the service area
• Replace damaged clips or screws with OEM fasteners for secure fit

This inner door is the dishwasher's inner panel that supports the door assembly and helps contain water and steam during cycles, restoring a secure, finished door surface. It replaces damaged or corroded inner door panels to improve sealing and appearance. What it does:

• Serves as the interior face of the dishwasher door and provides structural support for inner components
• Helps maintain a watertight seal and prevents leaks from the door area
• Replaces dented, cracked, or corroded inner panels that can trap moisture or cause cosmetic damage
• Restores proper alignment so the door closes and latches correctly

• 1 inner door panel

• Disconnect power and water supply before starting any repair
• Handle panel edges carefully; use gloves to avoid cuts and protect finish
• Installation typically requires removing the outer door panel and disconnecting inner fasteners—keep hardware organized for reassembly

Replace your range door seal to prevent heat loss and improve cooking efficiency. Install when worn, cracked, or loose. Verify fit with your model number.

This part is a replacement fixing kit and is a genuine OEM part manufactured by Bosch. This part has been sourced directly from the manufacturer and is intended to repair a broken or faulty door in a variety of different oven models. This fixing kit includes both of the door hinges that are necessary for repairing the oven door. These hinges are necessary for the user to control the opening rate of the door, as well as allow the door to remain ajar at an angle. When undergoing any repair work, make sure to always disconnect the power and gas supplies from the oven. It is highly recommended that work gloves are worn to for proper protection.This is an authentic replacement part and thus is suitable for use on several different models of ovens that have been manufactured by Bosch, Thermador, Gaggenau, and some other brands.

This glass front panel is the exterior replacement glass that restores the appliance's finished look and protects the underlying door and control area from scratches and wear. It fits into the door assembly to provide a clean, glossy surface. What it does:

• Replaces cracked, chipped, or heavily scratched front/door glass to restore appearance
• Protects internal components and trim from direct contact and debris
• Helps keep the door surface smooth and easy to clean
• Restores a secure fit when broken or loose glass affects the door finish

• One glass front panel

• Disconnect power to the appliance before starting any repair
• Handle glass with gloves and protective eyewear to avoid cuts
• Installation typically requires removing the door trim or bezel—follow the OEM service instructions for your model

This insulating part provides electrical and thermal isolation for internal appliance components, helping prevent shorting and reducing heat transfer where wiring or terminals meet sensitive parts. Use it to restore safe operation after damage or wear. What it does:

• Provides electrical insulation for terminals, connectors, or wiring to prevent shorts and arcing
• Reduces heat transfer between hot components and nearby wiring or plastic parts
• Helps maintain safe clearances and protects against chafing or contact-related failures
• Commonly replaced when cracked, melted, burned, or otherwise compromised

• One insulating part

• Always disconnect power (unplug appliance or switch off breaker) before servicing
• Verify correct orientation and seating; do not force the part into place
• Inspect surrounding wiring and terminals; replace any damaged connectors or wires

Replace a damaged heat shield causing nearby components to overheat or melt. This protective panel restores the heat barrier on your gas range.

The Trim Plate is an OEM part for Bosch ranges. This trim plate provides a sleek, finished look while also contributing to the handle's durability and ergonomics.

Causes of a bad Trim Plate can include excessive wear from routine use, accidental impacts that cause dents or scratches, or exposure to extreme temperatures leading to material degradation.

Symptoms of a bad trim plate include:

• Loosening or wobbling of the door handle, indicating a compromised fit.
• Visible damage like cracks, chips, or discoloration that affects the overall look of the range.
• Difficulty in opening or closing the oven door smoothly, which can impact cooking routines and safety.

This genuine OEM Bosch part is also compatible with Thermador, Gaggenau and select Kenmore models.
